TYPICAL APPLICATIONS

Sanitary sewer or on-site disposal pre-treatment.

PRODUCT OVERVIEW

Cloacina’s Stage I™ is a complete package wastewater treatment plant designed for small facilities and those with a limited footprint or future plans for expansion. Recognizing that a pump station is necessary for most wastewater treatment systems, Cloacina developed a compact unit that provides high-quality treatment in the footprint of the average pump station. Most Stage I™ models are incorporated into a standard lift station vessel and designed to treat less than 2000 Gallons Per Day (GPD). The unit can operate indefinitely as a treatment system, meeting an average discharge limit of 150 Total Suspended Solids (TSS)/150 Biochemical Oxygen Demand (BOD). Should flows, loading or discharge requirements dictate additional treatment equipment, the Stage I™ is easily converted into a lift station to supply the new downstream treatment system. Cloacina’s Stage I™ includes a cutting-edge SCADA/controls package that allows facility staff to remotely monitor and make adjustments to system parameters, collect information for reporting, view on-site video and verify the completion of routine maintenance. Stage I™ models can be self-contained or designed to fit into an existing buried vessel.

OPTIONAL FEATURES

  • Influent screen
  • pH adjustment system
  • 304 or 316 stainless steel equipment skid and hatch
  • Energy saving SCADA package upgrades
  • Effluent flow metering
  • Additional equipment sound attenuation
  • Thermal protection
  • Prefabricated control building/awnings
  • Odor mitigation equipment
  • Sludge disposal equipment
  • Site lighting
  • Bollards
  • Project management
  • Equipment installation

STANDARD FEATURES

  • Supervisory Control and Data Acquisition (SCADA) package
  • Medium bubble diffusers
  • All sensory/major equipment mounted on Cloacina’s Slide Rail System™
  • Sound attenuated positive displacement blowers
  • Prefabricated aluminum equipment skid with integral access hatch
  • Fiber Reinforced Polymer (FRP) lift station shell
  • Calculated flow monitoring
  • Solids management pump
  • Effluent pump
